Kubernetes Secrets with Examples

A Secret keeps passwords, tokens, and keys out of container images. This walkthrough creates common Secret types in secret-lab, then consumes application credentials through secretKeyRef, envFrom, and a read-only Secret volume.

Understand Kubernetes Secrets

What a Secret Stores

A Secret holds a small amount of confidential data—passwords, API tokens, SSH keys, or TLS material. An individual Kubernetes Secret is limited to 1 MiB. Secrets are namespace-scoped. Pods read Secret data as environment variables or as read-only files on a volume.

Cluster node access in this lab assumes SSH from your workstation.

Values in the data field are base64-encoded. That is encoding for transport and storage in the API, not encryption. Access is still governed by Kubernetes API authorization and RBAC. Use Secrets for credentials; use Kubernetes ConfigMaps for non-confidential configuration.

Create the lab namespace:

kubectl create namespace secret-lab

Sample output:

namespace/secret-lab created

Main Secret Types

Every Secret has a type that identifies its intended use. Opaque accepts arbitrary key-value data, while several built-in types require or validate particular key names or payload formats.

Most application credentials use Opaque (the default for kubectl create secret generic). Modern Pod ServiceAccount credentials normally use projected short-lived tokens rather than long-lived Secret objects—see Kubernetes ServiceAccounts for that flow.

Create Opaque Secrets

Create from Literal Values

Literal flags suit a few key-value pairs such as a database username and password. Use demonstration values in labs—not production credentials.

kubectl create secret generic app-credentials -n secret-lab --from-literal=username=demo-user --from-literal=password=demo-password

Sample output:

secret/app-credentials created

Confirm the object exists without dumping every value:

kubectl get secret app-credentials -n secret-lab

Example output; AGE varies:

NAME              TYPE     DATA   AGE
app-credentials   Opaque   2      0s

Inspect metadata and key sizes:

kubectl describe secret app-credentials -n secret-lab

Sample output:

Name:         app-credentials
Namespace:    secret-lab
Labels:       <none>
Annotations:  <none>

Type:  Opaque

Data
====
password:  13 bytes
username:  9 bytes

describe shows key names and byte counts, not the decoded values.

Create from Files

File-based creation loads key material from disk. The file content becomes the Secret value.

Save a demonstration API key:

printf '%s' 'sk-demo-api-key-12345' > api-key.txt

This command produces no output. printf avoids adding a trailing newline to the stored value.

Create the Secret with an explicit key name:

kubectl create secret generic application-keys -n secret-lab --from-file=api-key=api-key.txt

Sample output:

secret/application-keys created

Using api-key=path sets the Secret key to api-key regardless of the source filename. You can also point --from-file at a directory so each file becomes a separate key, or use --from-env-file for a simple KEY=value list—the same pattern as ConfigMap env files.

Create a Manifest with stringData

Declarative manifests are easier to review in Git—though you should not commit real Secret values to source control. Use stringData to supply plain strings; the API stores them in encoded data.

apiVersion: v1
kind: Secret
metadata:
  name: app-credentials-yaml
  namespace: secret-lab
type: Opaque
stringData:
  username: demo-user
  password: demo-password

Create the Secret from the manifest:

kubectl create -f app-credentials-yaml.yaml

Sample output:

secret/app-credentials-yaml created

stringData is a write-only input field. The API merges these plain strings into the encoded data field and does not return stringData when the Secret is read.

kubectl get secret app-credentials-yaml -n secret-lab -o yaml

Abridged sample output; server-generated metadata is omitted:

apiVersion: v1
data:
  password: ZGVtby1wYXNzd29yZA==
  username: ZGVtby11c2Vy
kind: Secret
metadata:
  name: app-credentials-yaml
  namespace: secret-lab
type: Opaque

When you must supply pre-encoded values directly, use data instead of stringData and base64-encode each value yourself.

Inspect and Decode a Secret

Base64 is reversible. Decoding proves the API stored your lab value—not that the Secret is encrypted.

kubectl get secret app-credentials -n secret-lab -o jsonpath='{.data.password}' | base64 -d
echo

Sample output:

demo-password

Use this only with demonstration credentials. In production, limit who can read Secret objects through RBAC rather than relying on encoding for secrecy.

Use Secrets in Pods

Inject One Key with secretKeyRef

Use secretKeyRef when the application expects one credential under a specific environment variable name. The container variable does not have to match the Secret key.

apiVersion: v1
kind: Pod
metadata:
  name: env-single
  namespace: secret-lab
spec:
  containers:
  - name: app
    image: busybox:1.36
    command: ["sh", "-c", "echo APP_DB_USER=$APP_DB_USER; sleep 3600"]
    env:
    - name: APP_DB_USER
      valueFrom:
        secretKeyRef:
          name: app-credentials
          key: username
  restartPolicy: Never

The Secret and key must exist before the Pod starts unless you set optional: true on the reference. Apply the Pod and wait until it is ready:

kubectl apply -f env-single.yaml

Sample output:

pod/env-single created

Wait for the Pod to become ready:

kubectl wait --for=condition=Ready pod/env-single -n secret-lab --timeout=60s

Sample output:

pod/env-single condition met

The command returns after the Pod reports the Ready condition. The kubelet decodes the Secret value when setting the environment variable:

kubectl exec env-single -n secret-lab -- printenv APP_DB_USER

Sample output:

demo-user

Environment variables are fixed at container start. Updating the Secret later does not change values in a running process—see how ConfigMap and Secret updates reach running Pods.

Import Keys with envFrom

When the application expects environment variable names that match Secret keys, envFrom imports every key in one block.

apiVersion: v1
kind: Pod
metadata:
  name: env-from
  namespace: secret-lab
spec:
  containers:
  - name: app
    image: busybox:1.36
    command: ["sh", "-c", "env | grep -E '^(username|password)=' | sort; sleep 3600"]
    envFrom:
    - secretRef:
        name: app-credentials
  restartPolicy: Never

Apply the Pod:

kubectl apply -f env-from.yaml

Sample output:

pod/env-from created

Wait for Ready, then read the imported variables:

kubectl wait --for=condition=Ready pod/env-from -n secret-lab --timeout=60s

Sample output:

pod/env-from condition met

Both keys appear as environment variables with matching names:

kubectl logs env-from -n secret-lab

Sample output:

password=demo-password
username=demo-user

Prefer explicit secretKeyRef entries when you need to rename keys, import only a subset, or mix Secrets with other env sources.

Mount Secret Keys as Files

A Secret volume projects each key as a filename. Mounts are read-only. Use a dedicated directory such as /etc/app-secret rather than masking files baked into the image.

Mount the app-credentials Secret at /etc/app-secret with selected keys and custom filenames:

apiVersion: v1
kind: Pod
metadata:
  name: volume-mount
  namespace: secret-lab
spec:
  containers:
  - name: app
    image: busybox:1.36
    command: ["sh", "-c", "ls -l /etc/app-secret; cat /etc/app-secret/username; echo; sleep 3600"]
    volumeMounts:
    - name: app-secret-vol
      mountPath: /etc/app-secret
      readOnly: true
  volumes:
  - name: app-secret-vol
    secret:
      secretName: app-credentials
      defaultMode: 0440
      items:
      - key: username
        path: username
      - key: password
        path: db-password
  restartPolicy: Never

The items list selects keys and renames the target files. defaultMode sets file permissions (here 0440). Apply the Pod:

kubectl apply -f volume-mount.yaml

Sample output:

pod/volume-mount created

Wait for the Pod, then inspect the mount:

kubectl wait --for=condition=Ready pod/volume-mount -n secret-lab --timeout=60s

Sample output:

pod/volume-mount condition met

The startup log lists the projected files and prints the username value:

kubectl logs volume-mount -n secret-lab

Example output; timestamps and symlink lengths vary:

total 0
lrwxrwxrwx    1 root     root            18 Jul 26 15:55 db-password -> ..data/db-password
lrwxrwxrwx    1 root     root            15 Jul 26 15:55 username -> ..data/username
demo-user

Confirm the projected file permissions:

kubectl exec volume-mount -n secret-lab -- stat -L -c '%a %n' /etc/app-secret/db-password /etc/app-secret/username

Sample output:

440 /etc/app-secret/db-password
440 /etc/app-secret/username

Normal Secret volumes are eventually refreshed when the source object changes. Files mounted with subPath do not—see how ConfigMap and Secret updates reach running Pods and subPath volume examples.

Create Typed Secrets

TLS Secret

TLS Secrets store a certificate and private key for Ingress controllers, web servers, or other TLS-terminated workloads. Generate or obtain tls.crt and tls.key first with OpenSSL—this section covers the Kubernetes object, not production certificate issuance.

openssl req \
  -x509 \
  -noenc \
  -newkey rsa:2048 \
  -keyout tls.key \
  -out tls.crt \
  -days 30 \
  -subj '/CN=web.example.com' \
  -addext 'subjectAltName=DNS:web.example.com'

OpenSSL prints key-generation progress to standard error. The sequence of dots and plus signs varies, so no fixed sample output is shown.

Create the TLS Secret from the generated certificate and private key:

kubectl create secret tls web-tls -n secret-lab --cert=tls.crt --key=tls.key

Sample output:

secret/web-tls created

Confirm the type and expected keys:

kubectl describe secret web-tls -n secret-lab

Example output; certificate and key byte counts vary:

Name:         web-tls
Namespace:    secret-lab
Labels:       <none>
Annotations:  <none>

Type:  kubernetes.io/tls

Data
====
tls.crt:  1168 bytes
tls.key:  1704 bytes

kubectl create secret tls requires a PEM-encoded certificate whose public key matches the supplied private key. How Ingress or an application consumes web-tls belongs in the relevant networking or workload guide.

Private Registry Secret

A registry Secret stores Docker config JSON for pulling images from a private registry.

kubectl create secret docker-registry registry-credentials -n secret-lab --docker-server=registry.example.com --docker-username=demo --docker-password=demo-pass --docker-email=demo@example.com

Sample output:

secret/registry-credentials created

The object type is kubernetes.io/dockerconfigjson:

kubectl get secret registry-credentials -n secret-lab -o jsonpath='{.type}{"\n"}'

Sample output:

kubernetes.io/dockerconfigjson

Reference the Secret in imagePullSecrets on the Pod spec, or attach it to a ServiceAccount so Pods using that account inherit pull credentials. Complete registry authentication, verification, and failure handling are covered in pull images from a private registry and ImagePullBackOff troubleshooting.

Immutable Secrets

Set immutable: true when Secret data should never change in place—similar to immutable ConfigMaps:

apiVersion: v1
kind: Secret
metadata:
  name: app-secret-immutable
  namespace: secret-lab
type: Opaque
stringData:
  token: release-token
immutable: true

Create the immutable Secret, then try to patch it:

kubectl create -f app-secret-immutable.yaml

Sample output:

secret/app-secret-immutable created

A patch against stringData is rejected:

kubectl patch secret app-secret-immutable -n secret-lab -p '{"stringData":{"token":"changed"}}'

Sample output:

The Secret "app-secret-immutable" is invalid: data: Forbidden: field is immutable when `immutable` is set

Once a Secret is marked immutable, you cannot change its data or set immutable back to false. Create a replacement Secret, or delete and recreate the object. Pods mounting a deleted immutable Secret should also be recreated.

Create a new Secret name and update the workload reference to ship new credentials. Replacement and rollout behaviour are covered in how ConfigMap and Secret updates reach running Pods.

Common Secret Problems

What's Next

• Kubernetes Multi-Tenancy and Workload Isolation
• Run Sandboxed Containers with RuntimeClass and gVisor
• Encrypt Kubernetes Pod Traffic with Cilium WireGuard

References

• Secrets — Secret types, limits, updates and immutable Secrets
• Managing Secrets using kubectl — literals and file-based creation
• Managing Secrets using Configuration File — data and stringData
• Distribute Credentials Securely Using Secrets — environment variables and Secret volumes
• kubectl create secret — imperative Secret commands
• kubectl create secret tls — TLS certificate and key requirements
• kubectl create secret docker-registry — registry Secret creation options
• kubectl wait — readiness wait behavior
• openssl req — self-signed certificate and private-key generation

Summary

You created Opaque application Secrets from literals, files, and stringData manifests, then verified metadata with kubectl get and describe. The same app-credentials Secret fed three consumption paths: one renamed environment variable through secretKeyRef, all keys through envFrom, and selected keys through a read-only volume.

TLS and registry Secrets use typed layouts—tls.crt/tls.key for kubernetes.io/tls and Docker config JSON for kubernetes.io/dockerconfigjson. Base64 in the API is encoding, not encryption; RBAC and operational practices protect access. When credentials change, plan for Pod recreation or application reload—environment variables and subPath mounts do not update in place.
