SSH Through a Jump Host with ProxyJump, ProxyCommand & SCP

This guide shows how to reach one Linux server through another using ProxyJump and ssh -J. You will also see how to copy files with scp -J, save shortcuts in ~/.ssh/config, and fix the errors beginners hit most often.

What is a jump host or bastion host?

A jump host is an intermediate computer that you use as a stepping stone to reach another server that your laptop cannot access directly.

You may also see the term bastion host. In this article, jump host and bastion host mean the same thing: a server that sits between your computer and a private SSH server.

For example, your laptop may be allowed to reach jump.example.com, while the server 10.10.10.20 can only be reached from that jump host.

Why companies use a jump host

Imagine a company has 50 internal Linux servers. Instead of exposing SSH port 22 on all 50 servers to the internet, administrators expose only one carefully controlled SSH server. You connect to that server first, and it provides the network path to the internal machines. That intermediate system is the jump host or bastion host.

This is different from SSH port forwarding, which tunnels application ports through an SSH session you already opened. A jump host is another SSH server that sits on the network path to the target.

What is the target server?

The target server (or just target) is the final server you actually want to log in to. It may have a private IP address or firewall rules that prevent your laptop from reaching it directly. A private server in this context means a machine that is not directly reachable from your workstation or the public internet without going through the jump host.

Your laptop
        |
        |  SSH
        v
Jump / bastion host
        |
        |  SSH connection carried to private network
        v
Target server (private)

For ProxyJump to work:

• Your laptop must reach the jump host
• The jump host must reach the target server's SSH port
• The target does not need to be directly reachable from your laptop

If you use a hostname such as target.internal instead of an IP address, the jump host must usually know how to resolve that name — your laptop only needs to reach the bastion.

Quick answer: SSH through a jump host

ProxyJump tells your local SSH client: connect to the jump host first, and use it as the network path to the final server. The short command-line option for ProxyJump is -J.

For OpenSSH 7.3 and later:

ssh -J jumpuser@jump.example.com admin@10.10.10.20

In that command:

• jumpuser — your account on the jump host
• jump.example.com — the jump host
• admin — your account on the target server
• 10.10.10.20 — the target server you want to reach

Equivalent long form:

ssh -o ProxyJump=jumpuser@jump.example.com admin@10.10.10.20

Use -J for one-off connections and entries in ~/.ssh/config for hosts you open regularly. OpenSSH defines -J as the command-line shortcut for ProxyJump, including comma-separated routes through more than one jump host.

How the connection works

The jump host does not log you into the final server on your behalf. It carries the network connection from your SSH client to the target server. You do not open a shell on the bastion and run a second ssh command there — your original SSH client keeps control of the target session.

There are two SSH authentications:

• Authentication #1: your client proves who you are to the jump host
• Authentication #2: your client proves who you are to the target server

ProxyJump does not log into the bastion and run ssh target there. A private key stored only on the jump host is not used automatically — keys on your laptop authenticate to the final server.

Run a one-hop login:

ssh -J jumpuser@jump.example.com admin@10.10.10.20

I verified the same path on RHEL 10.2 with a local bastion and a target that only the bastion could reach:

ssh -J root@127.0.0.1 -p 2222 targetuser@172.18.0.2 'hostname; echo PROXYJUMP_OK'

target.internal
PROXYJUMP_OK

Different users and ports on the jump host and target

The jump host and target can each use their own settings:

• Username
• SSH port
• SSH key
• Authentication policy

When sshd on the jump host listens on a non-default port, append :port to the jump target:

ssh -J jumpuser@jump.example.com:2222 admin@10.10.10.20

Use -p on the final destination when the target server does not listen on port 22:

ssh -J jumpuser@jump.example.com -p 2200 admin@10.10.10.20

Configure ProxyJump in ~/.ssh/config

For regular use, save SSH settings in ~/.ssh/config. A Host block is a named group of settings for a hostname or alias — for example Host bastion or Host private-server.

Give the jump host and the target server their own Host blocks:

Host bastion
    HostName jump.example.com
    User jumpuser

Host private-server
    HostName 10.10.10.20
    User admin
    ProxyJump bastion

After that, a short alias is enough:

ssh private-server

Separate SSH keys for jump host and target

An IdentityFile line points SSH at the private key file to use for that Host block.

Host bastion
    HostName jump.example.com
    User jumpuser
    IdentityFile ~/.ssh/jump_ed25519
    IdentitiesOnly yes

Host private-server
    HostName 10.10.10.20
    User admin
    IdentityFile ~/.ssh/private_ed25519
    IdentitiesOnly yes
    ProxyJump bastion

Command-line and destination Host options are not automatically applied to a jump host. OpenSSH applies most command-line flags to the destination connection, not to the jump host — configure bastions in their own Host blocks.

A common trap:

ssh -i ~/.ssh/target_key -J bastion target

That does not mean “use target_key everywhere.” -i belongs to the destination connection. If the bastion needs another key, give the bastion its own Host block and IdentityFile.

When several Host, wildcard, or Include blocks overlap, print the effective settings before you connect:

ssh -G private-server | grep -Ei 'hostname|user|port|identityfile|proxyjump|proxycommand'

user admin
hostname 10.10.10.20
port 22
identityfile ~/.ssh/private_ed25519
proxyjump bastion

SSH through multiple jump hosts

Each intermediate SSH server in the route is called a hop.

One jump host:

Laptop → Jump 1 → Target

Two jump hosts (often called multi-hop SSH):

Laptop → Jump 1 → Jump 2 → Target

OpenSSH accepts multiple jump hosts separated by commas:

ssh -J user1@jump1.example.com,user2@jump2.internal admin@10.20.30.40

Equivalent configuration:

Host jump1
    HostName jump1.example.com
    User user1

Host jump2
    HostName jump2.internal
    User user2

Host private-server
    HostName 10.20.30.40
    User admin
    ProxyJump jump1,jump2

Then:

ssh private-server

Prefer the comma-separated ProxyJump form over nested ProxyCommand chains for modern multi-hop SSH bastions.

Copy files through a jump host with SCP

Modern scp has its own -J option and follows the same jump path as ssh.

Upload a file through a jump host

Push a local file to the target server in one step:

scp -J jumpuser@jump.example.com file.txt admin@10.10.10.20:/tmp/

Lab equivalent:

scp -J root@127.0.0.1 -P 2222 /tmp/scp-test.txt targetuser@172.18.0.2:/tmp/scp-via-j.txt

The target returned:

scp via ProxyJump

Download a file through a jump host

Pull a remote file back to the current directory:

scp -J jumpuser@jump.example.com admin@10.10.10.20:/var/log/app.log .

Copy a directory recursively

Add -r when the source path is a directory tree:

scp -r -J jumpuser@jump.example.com ./project admin@10.10.10.20:/tmp/

scp -J passes the ProxyJump setting through SSH. You can also use the generic option form when you prefer it:

scp -o ProxyJump=jumpuser@jump.example.com file.txt admin@10.10.10.20:/tmp/

Reuse ~/.ssh/config for SSH and SCP

With the private-server stanza from earlier, SSH and SCP share the same alias:

ssh private-server

Copy through that alias the same way:

scp file.txt private-server:/tmp/

That is cleaner than repeating -J on every transfer. See the SCP command cheat sheet for recursion, limits, and other copy flags.

SCP through multiple jump hosts

Comma-separated jump hosts work for SCP the same way they do for SSH:

scp -J user1@jump1.example.com,user2@jump2.internal file.txt admin@10.20.30.40:/tmp/

Note about modern SCP

Since OpenSSH 9.0, scp uses the SFTP protocol for file transfers by default. The command-line interface and -J / ProxyJump behavior stay the same. Use scp -O only when you specifically need the legacy SCP protocol.

SFTP and rsync through the same jump host

When ProxyJump is already defined for private-server in ~/.ssh/config, other OpenSSH-based tools can reuse the same route without repeating -J:

sftp private-server

rsync over SSH follows the same config alias when you use the remote shell transport:

rsync -av ./project/ private-server:/tmp/project/

Tools that use OpenSSH as their transport can reuse the same ProxyJump route from ~/.ssh/config. For example, sftp and rsync over SSH can use the private-server alias directly.

Do you need SSH agent forwarding?

No. Ordinary ProxyJump access does not require ForwardAgent yes. Your local SSH client can authenticate to the final target with a private key that never leaves the workstation.

Avoid these common mistakes:

• Do not copy the target private key to the jump host
• Do not enable agent forwarding just because a bastion sits in the path

If you need agent forwarding for another workflow, treat it as a separate hardening decision.

ProxyJump vs ProxyCommand

Do not set both ProxyJump and ProxyCommand for the same destination. OpenSSH uses whichever value it obtains first for that connection.

ProxyCommand is an older, more flexible way to tell SSH how to create the connection path. For a normal SSH jump or bastion host, prefer ProxyJump. Keep ProxyCommand when you need a non-SSH proxy or another special connection method.

ProxyCommand: flexible alternative with ssh -W

Before ProxyJump, bastion access often looked like this:

ssh -o 'ProxyCommand=ssh -W %h:%p jumpuser@jump.example.com' admin@10.10.10.20

Configuration equivalent:

Host private-server
    HostName 10.10.10.20
    User admin
    ProxyCommand ssh -W %h:%p bastion

• %h expands to the target hostname.
• %p expands to the target SSH port.
• ssh -W host:port carries the target connection through the bastion SSH session.
• nc on the bastion is not required for this pattern.

SSH jump host vs HTTP or SOCKS proxy

This page is titled ssh-proxy, but not every “proxy” in SSH means a jump host. Readers often mix up two different ideas:

If the intermediate machine accepts SSH connections, use ProxyJump. If it is an HTTP or SOCKS proxy rather than an SSH server, use ProxyCommand with a compatible client.

SSH through an HTTP CONNECT proxy

Generic nc example from the OpenBSD documentation:

ssh -o 'ProxyCommand=nc -X connect -x proxy.example.com:8080 %h %p' user@server.example.com

Configuration:

Host server-via-proxy
    HostName server.example.com
    User user
    ProxyCommand nc -X connect -x proxy.example.com:8080 %h %p

nc implementations differ between distributions. On RHEL with Nmap ncat, the proxy flags look like this:

ssh -o 'ProxyCommand=ncat --proxy-type http --proxy proxy.example.com:8080 %h %p' user@server.example.com

Match the proxy client to the package your distribution ships.

Troubleshooting ProxyJump and jump hosts

When a jump login fails before the target is tried, test the SSH connection to the bastion alone (ssh jumpuser@jump.example.com) before you add -J.

Internally, ProxyJump uses SSH TCP forwarding through the bastion. You do not need a shell command on the bastion, but sshd must allow the forwarding channel that carries the target connection — which is why AllowTcpForwarding yes matters when you see administratively prohibited.

When diagnosis is unclear, run one failing connection with ssh -vvv -J … and note where it breaks:

• Client → bastion authentication or forwarding
• Bastion → target TCP connection
• Target SSH authentication after the tunnel is up

From the lab bastion, the private target port was reachable before ProxyJump was tested:

nc -vz 172.18.0.2 2222

Connection to 172.18.0.2 2222 port [tcp/*] succeeded!

Summary

A jump host or bastion host is an intermediate SSH server that provides the network path to a target server your laptop cannot reach directly. ProxyJump (and the -J shortcut) tells your SSH client to use that path in one command, with separate authentication to the jump host and the target.

Put recurring routes in ~/.ssh/config with separate Host blocks for the bastion and the destination, especially when usernames, ports, or keys differ. Use comma-separated ProxyJump values when you need more than one hop, and scp -J (or the same config alias) to copy files along the same path.

Reserve ProxyCommand for HTTP/SOCKS proxies and other non-SSH connection methods. If a jump connection fails, test the bastion alone, confirm the bastion can reach the target SSH port, then read ssh -vvv to see which hop broke.

References

• ssh(1) — -J and ProxyJump — command-line jump host shortcut
• ssh_config(5) — ProxyJump — config-file jump hosts and comma-separated hops
• ssh_config(5) — ProxyCommand — custom proxy transports
• scp(1) — -J — SCP through a jump host
