Create a Root Certificate Authority with OpenSSL

A root CA is your own trust anchor: a private signing key plus a self-signed X.509 certificate that other systems can choose to trust. Common uses include:

• Internal HTTPS and mTLS between services you operate
• VPNs and homelab PKI when you control every client
• Lab and staging environments before you buy public certificates

It is not a substitute for a publicly trusted CA on the open internet.

This walkthrough covers creating and verifying that root certificate with the OpenSSL CLI. It does not cover:

• Operating an issuing CA with index.txt, serial files, and openssl ca (a separate workflow)
• Installing the root into Debian or RHEL trust stores (see the trust-store guide when you distribute root-ca.crt)

Quick answer

A root CA pairs a private key with a self-signed certificate whose extensions mark it as a certification authority:

• basicConstraints = critical, CA:true
• keyUsage that includes keyCertSign (and usually cRLSign)

For a private root on Linux under ~/private-root-ca, work through these steps in order (commands and sample output for each step follow in the sections below):

• Step-1 — Create ~/private-root-ca/private and restrict directory permissions.
• Step-2 — Generate a 4096-bit RSA root key with openssl genpkey (passphrase-protected with -aes-256-cbc, or unencrypted for an isolated lab), then run chmod 400 on the key file.
• Step-3 — Issue the self-signed root certificate with openssl req -new -x509 and -addext for CA extensions.
• Step-4 — Verify subject and issuer, CA:TRUE and key usage, openssl verify, and the SHA-256 fingerprint.
• Step-5 — Protect root-ca.key and distribute only root-ca.crt.
• Step-6 — Sign an intermediate CA for day-to-day issuance instead of signing server certificates directly from the root.

What is a root CA?

In PKI and certificate authority terms, a root certificate authority sits at the top of a chain:

• Its certificate is self-signed (subject equals issuer).
• Clients that trust the root accept descendant certificates signed under that hierarchy.

A self-signed server certificate is also self-signed, but it identifies one host or service, not a signing authority. For a single-host TLS file without CA extensions, see generate a self-signed certificate with OpenSSL. The root-versus-server distinction is in X.509 extensions, not in the phrase “self-signed.”

Root CA vs self-signed server certificate

Root CA vs intermediate CA

A common PKI design is to:

• Keep the root offline and use an intermediate CA online for day-to-day signing
• Limit blast radius if the issuing key is compromised

This page stops at the root; the next guide builds root, intermediate, and leaf certificates.

┌───────────────────────────────┐
│            Root CA            │
│     (offline trust anchor)    │
│  root-ca.crt / root-ca.key    │
└───────────────┬───────────────┘
                │ signs
                ▼
┌───────────────────────────────┐
│        Intermediate CA        │
│         (issuing CA)          │
└───────────────┬───────────────┘
                │
         ┌──────┴──────┐
         ▼             ▼
 ┌───────────────┐ ┌───────────────┐
 │  Server cert  │ │  Client cert  │
 └───────────────┘ └───────────────┘

  Distribute: root-ca.crt
  Protect:     root-ca.key

Prerequisites

You need the openssl binary. On Ubuntu and Debian, install OpenSSL with apt if it is missing; most server images already include it.

Confirm the major version—this walkthrough uses OpenSSL 3.x syntax (genpkey, -addext):

openssl version

OpenSSL 3.5.5 27 Jan 2026 (Library: OpenSSL 3.5.5 27 Jan 2026)

Before you generate keys:

• Work in a directory only you can read (chmod 700 on private/).
• You do not need root unless you later install root-ca.crt into a system-wide trust store.

Step 1: Create a working directory for the root CA

Generate keys and certificates in a dedicated tree so permissions stay obvious. Create the layout under your home directory:

mkdir -p ~/private-root-ca/private

Restrict the directory so only your user can list or create files there:

chmod 700 ~/private-root-ca/private

The private key is written directly into the restricted private/ directory.

Step 2: Generate the root CA private key

Use openssl genpkey for OpenSSL 3.x. Older tutorials often use openssl genrsa; genpkey is the general interface for RSA and ECC—see generate an ECC certificate with OpenSSL when you prefer an elliptic-curve root.

With a passphrase (recommended)

Passphrase encryption protects the key file if it is copied off disk. OpenSSL prompts when you create the key and again when you use it in req:

openssl genpkey -algorithm RSA -aes-256-cbc -pkeyopt rsa_keygen_bits:4096 -out ~/private-root-ca/private/root-ca.key

Choose a passphrase you can store securely. Without it, the encrypted root key is unusable. The main options on this command:

• -algorithm RSA — RSA key (widely compatible for a root)
• -aes-256-cbc — encrypt the key file with AES-256-CBC; OpenSSL prompts for the passphrase
• -pkeyopt rsa_keygen_bits:4096 — 4096-bit modulus
• -out …/root-ca.key — write the key directly into your restricted private/ directory

Without a passphrase

Skip -aes-256-cbc when you need a throwaway lab root or scripted signing where another layer (offline storage, HSM, or short-lived VM) already controls access. The key file is readable by anyone who can read the file and your chmod settings:

openssl genpkey -algorithm RSA -pkeyopt rsa_keygen_bits:4096 -out ~/private-root-ca/private/root-ca.key

genpkey exits silently on success. Use the same -algorithm RSA, -pkeyopt rsa_keygen_bits:4096, and -out paths as above, but omit -aes-256-cbc so the key is stored in plain PEM. Do not use an unencrypted root key on shared hosts or long-lived production PKI unless policy explicitly allows it.

Restrict the private key file

Whether the key is encrypted or not, remove group and other access:

chmod 400 ~/private-root-ca/private/root-ca.key

Passphrase or plain key?

If someone copies the root private key, they can issue certificates that every trust store honoring your root will accept. Mitigations include:

• AES-256-CBC encryption at key generation (-aes-256-cbc) when humans or break-glass processes unlock the key
• chmod 400 so other local users cannot read the file
• Offline storage or an HSM when the root is not signing
• Omitting the passphrase only when the environment is isolated and the risk is understood

Use the root key sparingly, typically to sign an intermediate, not end-entity certificates.

Step 3: Create the self-signed root CA certificate

Issue the root certificate with openssl req -new -x509, SHA-256, and explicit extensions via -addext so CA properties are visible in the command.

openssl req -new -x509 \
  -key ~/private-root-ca/private/root-ca.key \
  -sha256 \
  -days 3650 \
  -out ~/private-root-ca/root-ca.crt \
  -subj "/C=IN/O=Example/CN=Example Root CA" \
  -addext "basicConstraints=critical,CA:true,pathlen:1" \
  -addext "keyUsage=critical,keyCertSign,cRLSign" \
  -addext "subjectKeyIdentifier=hash" \
  -addext "authorityKeyIdentifier=keyid:always,issuer"

OpenSSL prompts for the key passphrase only when root-ca.key is encrypted. The flags and values in this command mean:

• req — certificate request tool; combined with -x509 it builds and signs the certificate in one step.
• -new — create a new request or certificate (do not reuse an old CSR on disk).
• -x509 — write a self-signed X.509 certificate instead of outputting a CSR for another CA to sign.
• -key ~/private-root-ca/private/root-ca.key — private key that signs the certificate (must match the public key embedded in the cert).
• -sha256 — sign the certificate with SHA-256 (use a modern digest, not SHA-1).
• -days 3650 — validity period of 3,650 days from issuance (~10 years). Pick a shorter or longer value to match your PKI policy and intermediate or leaf lifetimes.
• -out ~/private-root-ca/root-ca.crt — PEM file for the root certificate (safe to copy to clients; not the private key).
• -subj "/C=IN/O=Example/CN=Example Root CA" — distinguished name baked into subject and issuer (self-signed, so they match):
  • C=IN — country code
  • O=Example — organization
  • CN=Example Root CA — common name shown as the CA title
• -addext "basicConstraints=critical,CA:true,pathlen:1" — marks the cert as a CA; critical means reject if unsupported; pathlen:1 allows one subordinate CA level below this root (root → intermediate → leaf).
• -addext "keyUsage=critical,keyCertSign,cRLSign" — CA may sign other certificates and CRLs; required profile when keyUsage is present on a CA cert.
• -addext "subjectKeyIdentifier=hash" — SKI derived from the public key (helps chain building).
• -addext "authorityKeyIdentifier=keyid:always,issuer" — AKI points at this cert’s key and issuer DN (on a self-signed root, SKI and AKI refer to the same anchor).

After the root certificate expires:

• You do not extend the old file in place; you issue a new root certificate.
• You may reuse the existing private key where policy allows, or generate a new root key during rollover.
• See renew an expired root CA certificate for the OpenSSL steps.

For a larger CA workflow, move these extensions into openssl.cnf from the certificate chain guide instead of repeating -addext on every command.

Required CA extensions

A proper root CA certificate in this guide includes:

• basicConstraints = critical, CA:TRUE (and pathlen when you want a depth limit)
• keyUsage = critical, keyCertSign, cRLSign

How those fields interact:

• basicConstraints with CA:TRUE is what marks the certificate as a CA (not merely self-signed).
• keyUsage is not required on every X.509 CA certificate the way CA:TRUE is.
• When keyUsage is present, it must include keyCertSign for a signing CA.
• Critical keyUsage with keyCertSign and cRLSign fits a root that signs intermediates and may publish CRLs.

A self-signed certificate without CA:TRUE is not a root CA, even when subject and issuer match. For more extension patterns, see add x509 extensions to a certificate.

Choosing a pathlen value

pathlen is the maximum number of non-self-issued CA certificates that may appear below this CA in a valid chain. It is a deliberate design choice, not a limit on how many intermediate certificates you may ever issue over time.

• pathlen:1 — at most one additional CA level below the root, which fits root → intermediate → leaf.
• pathlen:0 — this CA may issue end-entity certificates, but no subordinate CA certificate may appear beneath it.
• Omit pathlen — no depth constraint in the extension (more flexible if you may add CA levels later).

If you intend a single CA level between the root and leaf certificates, pathlen:1 is appropriate. Many examples omit pathlen on roots that might grow a deeper hierarchy later.

Step 4: Verify the root CA certificate

Work through these checks in order:

• Subject and issuer point at the same DN (self-signed root).
• basicConstraints and keyUsage show CA:TRUE and certificate signing.
• openssl verify returns OK when the root file is its own trust anchor.
• SHA-256 fingerprint is recorded before you distribute root-ca.crt.

Check subject and issuer

A root CA should list the same distinguished name for subject and issuer:

openssl x509 -in ~/private-root-ca/root-ca.crt -noout -subject -issuer -dates

subject=C=IN, O=Example, CN=Example Root CA
issuer=C=IN, O=Example, CN=Example Root CA
notBefore=Oct 17 13:03:14 2026 GMT
notAfter=Oct 14 13:03:14 2036 GMT

Matching subject and issuer confirms the cert is self-signed. notBefore and notAfter bound the validity window.

Verify CA:TRUE and key usage

Scan the extensions instead of dumping the entire certificate:

openssl x509 -in ~/private-root-ca/root-ca.crt -noout -text | grep -A2 'Basic Constraints\|Key Usage'

            X509v3 Basic Constraints: critical
                CA:TRUE, pathlen:1
            X509v3 Key Usage: critical
                Certificate Sign, CRL Sign

In the extension output, expect:

• CA:TRUE (and pathlen:1 if you used that -addext value)
• Certificate Sign under Key Usage
• CRL Sign when you included cRLSign

Confirm the self-signed chain with openssl verify

Pass the same PEM file as both the trust anchor (-CAfile) and the certificate under test. When validation succeeds:

• OpenSSL prints OK and the full path to root-ca.crt.
• That confirms signature and basic chain handling for this single-file check.
• It does not replace the subject, extension, and key-usage checks above.

openssl verify -CAfile ~/private-root-ca/root-ca.crt ~/private-root-ca/root-ca.crt

/home/user/private-root-ca/root-ca.crt: OK

Record the SHA-256 fingerprint

Before you distribute root-ca.crt, record its fingerprint so clients can confirm they received the expected trust anchor:

openssl x509 -in ~/private-root-ca/root-ca.crt -noout -fingerprint -sha256

sha256 Fingerprint=19:94:F3:C4:A4:06:04:88:1E:78:9A:D8:BB:DD:3C:37:2C:FA:1F:CB:B1:8F:45:BB:E1:C3:B6:19:68:E2:BF:17

Share the fingerprint through a trusted channel, for example:

• Out-of-band message to the team importing the root
• Configuration management or secrets store metadata
• An internal runbook entry paired with the PEM file

Your fingerprint will differ because the key material is unique.

Step 5: Protect the root CA private key

Treat root-ca.key as the highest-value secret in your PKI:

• Do not copy it onto application servers or into container images.
• Do not commit it to git or paste it into tickets.
• Distribute only root-ca.crt to clients that must trust your hierarchy.
• Keep the root key offline when practical; sign intermediates in a controlled session.

If you must back up the key:

• Encrypt the backup media or archive
• Store it separately from root-ca.crt
• Use the same caution as for the live root-ca.key file

Step 6: What to do next

Create an intermediate CA and certificate chain

A typical hierarchy:

• Root CA signs one intermediate CA (short, controlled root signing sessions).
• The intermediate signs server and client leaf certificates day to day.
• The root key stays offline; issuance happens on the intermediate.

Follow OpenSSL create certificate chain: root, intermediate and leaf for openssl ca layout, index.txt, CSRs, and fullchain.pem.

Add the root CA to the Linux trust store

Creating root-ca.crt does not automatically trust the CA in:

• Linux distribution CA bundles
• Desktop browsers
• Java cacerts or application-specific trust stores

Import the certificate only with install and trust a CA certificate on Linux. Never install the private key into a trust store.

Troubleshooting

Summary

You can create a private root CA on Linux with OpenSSL 3.x by generating a 4096-bit RSA root key (passphrase-protected or plain, depending on policy), issuing a self-signed root certificate with CA:TRUE and keyCertSign, and verifying subject/issuer match, extensions, openssl verify, and the SHA-256 fingerprint. That certificate is only the trust anchor: keep root-key use rare, sign an intermediate for routine issuance, and distribute only the public root certificate to clients.

openssl ca databases, CRL state, and leaf certificate signing belong in the dedicated certificate chain article, not in root creation. Public websites still need a publicly trusted CA; internal infrastructure can use your root when trust stores and private keys are managed deliberately.

References

• OpenSSL genpkey documentation
• OpenSSL req documentation
• OpenSSL certificate verification (openssl verify)
• OpenSSL ca command (sample CA application)
