Idle SSH Sessions: Disconnect or Keep Them Alive on Linux

“Idle SSH” can mean two different things: the user has stopped interacting with the shell, or the connection has stopped carrying network traffic long enough for a NAT or firewall to expire it. OpenSSH uses different settings for these cases. Server admins and remote users often want opposite outcomes: drop ghost sessions on the server, or keep a quiet laptop session alive through a home router.

OpenSSH splits the work cleanly. sshd settings on the server decide when to probe or drop a client. ssh client settings on the workstation that runs ssh decide whether the client sends its own keepalive traffic. This guide tests both sides on vm1.lab.example (server) and vm2.lab.example (client).

Server settings vs client settings

Misplacing these directives is the most common mistake on this topic. Edit the SSH server when you control sshd; edit the SSH client when your session dies on the path between your laptop and the server.

All procedural steps below name which lab host runs the command. Unless noted, server steps run on vm1.lab.example and client steps run on vm2.lab.example.

What the keepalive directives do

From the OpenSSH manuals:

• ClientAliveInterval (server): after this many seconds with no data from the client, sshd sends an encrypted keepalive request. Default 0 disables those probes.
• ClientAliveCountMax (server): how many consecutive probes may go unanswered before sshd closes the session. 0 disables termination from this mechanism — it does not force a faster disconnect.
• ServerAliveInterval (client): the ssh client sends its own keepalive traffic when the session is quiet. Use this when a middlebox drops idle TCP flows even though both sides are healthy.
• ServerAliveCountMax (client): how many unanswered client keepalive cycles occur before ssh gives up.
• TCPKeepAlive (server): enables or disables OS-level TCP keepalive probes. Separate from ClientAlive*; useful for detecting some dead peers but not a substitute for encrypted SSH keepalives.

For a keyboard-idle but otherwise healthy session, the OpenSSH client normally answers server ClientAlive probes automatically. OpenSSH documents the configured disconnect delay as approximately ClientAliveInterval × ClientAliveCountMax after the connection becomes unresponsive; observed wall-clock time can vary depending on when the client last sent data and on scheduling.

If your goal is to close an SSH shell because its channel has no traffic, recent OpenSSH versions also provide ChannelTimeout. That measures inactivity on an SSH channel, not merely keyboard silence in every case — activity on the relevant channel resets its timeout, and it is separate from connection-level keepalive detection with ClientAlive*. See ChannelTimeout in sshd_config(5).

Read effective SSH server values

Before you change timeouts, read what sshd actually runs. Drop-in files under /etc/ssh/sshd_config.d/ override the main file.

On the server (vm1.lab.example), print the merged configuration:

sudo sshd -T | grep -iE 'clientalive|tcpkeepalive|channeltimeout'

Sample output on a fresh RHEL 10 install before this lab adds overrides:

clientaliveinterval 0
clientalivecountmax 3
tcpkeepalive yes
channeltimeout none

clientaliveinterval 0 means the server is not actively probing idle clients yet. tcpkeepalive yes is the RHEL default at the TCP layer.

Drop unresponsive clients on the server

When you want sshd to close sessions whose client stops answering keepalive probes — crashed laptop, suspended process, or one-way network failure — set ClientAliveInterval and a non-zero ClientAliveCountMax on the server.

Create a drop-in on vm1.lab.example (adjust seconds for production; short values are easier to test):

# /etc/ssh/sshd_config.d/99-client-alive.conf
ClientAliveInterval 15
ClientAliveCountMax 1

Validate syntax and reload sshd without dropping existing sessions:

sudo sshd -t

That command exits silently when the file parses cleanly.

Reload the running daemon:

sudo systemctl reload sshd

Confirm the new values are active:

sudo sshd -T | grep -i clientalive

Sample output:

clientaliveinterval 15
clientalivecountmax 1

OpenSSH documents the timeout as approximately ClientAliveInterval × ClientAliveCountMax. With 15 and 1, expect roughly 15 seconds after the connection becomes unresponsive — not keyboard-idle, but a client that stops answering keepalive probes. Observed timing in a test can vary depending on when the connection last exchanged data.

A responsive client stays connected while idle

From vm2.lab.example, start a quiet remote command — no typing, but the client still answers server probes:

ssh root@192.168.56.116 sleep 120

That session stayed up for the full two minutes in this lab even with ClientAliveInterval 15. A user who stops typing is not necessarily an unresponsive SSH client.

If the client stops responding because its process, host, or network path fails, sshd eventually disconnects it according to ClientAliveInterval and ClientAliveCountMax. Use list active SSH connections (who, w, or ss -tnp sport = :22) on the server while you test policy changes.

Keep idle sessions alive from the client

When the problem is a NAT router, VPN concentrator, or firewall that forgets quiet TCP flows, configure keepalives on the SSH client — the machine where you run ssh.

On vm2.lab.example, scope the settings to one server in ~/.ssh/config:

Host vm1.lab.example 192.168.56.116
    ServerAliveInterval 60
    ServerAliveCountMax 3

Ask OpenSSH to print the merged client options for that host:

ssh -G vm1.lab.example | grep -i alive

Sample output:

serveraliveinterval 60
serveralivecountmax 3
tcpkeepalive yes

After 60 seconds without receiving data from the server, the client sends an encrypted keepalive request. After three failed rounds it exits — long enough to survive most home-router idle timers without hammering the server every few seconds.

This does not change sshd on the remote host. It only affects connections initiated from hosts that use this client configuration.

TCPKeepAlive on the server

TCPKeepAlive in /etc/ssh/sshd_config toggles whether the kernel sends TCP-level keepalive probes on SSH connections. On this lab host the merged server config already showed tcpkeepalive yes in the earlier sshd -T step.

TCPKeepAlive is enabled by default in this tested configuration. It uses kernel TCP keepalives and is separate from the encrypted ClientAlive* / ServerAlive* mechanisms. You normally do not need to change it just to configure the SSH keepalive behavior covered here.

Troubleshooting

References

• sshd_config(5) — OpenSSH daemon configuration file
• ssh_config(5) — OpenSSH client configuration file
• Red Hat Enterprise Linux 10 — Secure communication with OpenSSH

Summary

Idle SSH timeouts depend on which side of the connection you configure. On the server (vm1.lab.example in this lab), ClientAliveInterval and a positive ClientAliveCountMax make sshd probe the client and drop sessions that stop answering — but a normal OpenSSH client still answers those probes when you simply stop typing. OpenSSH describes that mechanism as detecting unresponsive connections; ClientAliveCountMax 0 disables termination from it. For channel-level shell inactivity, see ChannelTimeout in the upstream manual.

On the client (vm2.lab.example), ServerAliveInterval and ServerAliveCountMax keep quiet TCP flows alive through NAT and stateful firewalls. TCPKeepAlive is a separate kernel-level option on the server and is not the same knob as the encrypted keepalive settings in this walkthrough.

Always verify merged settings with sudo sshd -T on the server and ssh -G host on the client before you assume a timeout change took effect. For stuck interactive sessions that ignore keepalives, see kill or disconnect a hung SSH session instead of tuning idle timers alone.
