Golang Shiny: windows, events, and drawing with x/exp/shiny

Shiny is a low-level, cross-platform experiment for opening windows, reading input, and pushing pixels from Go. It is not part of the Go standard library and it is not a full widget toolkit: you draw into buffers (or textures) and wire your own layout and controls.

When I wrote this guide I built and ran the programs on 64-bit Linux with Go 1.25 and a normal graphical desktop. The golang.org/x/exp/shiny pseudo-version I pinned while writing was v0.0.0-20260611194520-c48552f49976.

What Is Golang Shiny?

Shiny splits responsibilities across a few packages:

• golang.org/x/exp/shiny/driver — Main boots the right backend (for example X11 on Linux) and hands you a screen.Screen.
• golang.org/x/exp/shiny/screen — Screen creates Buffer values (CPU-side RGBA images), Texture values, and Window values.
• golang.org/x/mobile/event/... — portable lifecycle, paint, key, mouse, and size events you receive from Window.NextEvent.

Upstream examples live under shiny/example in the exp repository.

Is Shiny an official Go GUI framework?

It lives in the Go project’s experimental tree (x/exp), which explicitly warns that APIs may change or disappear. It is “official” only in the sense that it is maintained alongside other golang.org/x/... experiments—not in the sense of a supported, batteries-included application framework.

Install and Set Up Golang Shiny

You need a working Go toolchain and the usual OS libraries for your driver (on Linux, X11-related development packages are commonly required so GLFW/Xgb can link).

Create a Go module and add x/exp/shiny

Create a project directory, then:

mkdir shiny-demo && cd shiny-demo
go mod init example.com/shiny-demo
go get golang.org/x/exp/shiny@latest

go get records golang.org/x/exp/shiny in go.mod and pulls compatible versions of indirect dependencies (including golang.org/x/mobile for events). Note: recent Shiny releases may require a newer Go version than older LTS installs; if go get reports a toolchain constraint, upgrade Go or pin an older Shiny pseudo-version that matches your toolchain.

Create Your First Shiny Window

Every program follows the same skeleton: call driver.Main with a function that receives screen.Screen, create a window, then loop on NextEvent.

Understand driver.Main, Screen, and Window

• driver.Main(func(s screen.Screen) { ... }) — starts the platform driver. The closure may run on the OS UI thread; keep event handling cooperative.
• Screen — factory for this driver’s buffers, textures, and windows.
• Window — implements EventDeque (NextEvent, Send, …), Upload, and Publish.

The listing below opens a titled window, tracks size.Event so the backing buffer matches the drawable area, fills it blue, and uploads on each paint.Event. Quitting the window emits lifecycle.StageDead.

package main

import (
	"image"
	"image/color"
	"image/draw"
	"log"

	"golang.org/x/exp/shiny/driver"
	"golang.org/x/exp/shiny/screen"
	"golang.org/x/mobile/event/lifecycle"
	"golang.org/x/mobile/event/paint"
	"golang.org/x/mobile/event/size"
)

func main() {
	driver.Main(func(s screen.Screen) {
		w, err := s.NewWindow(&screen.NewWindowOptions{
			Width:  400,
			Height: 300,
			Title:  "Shiny first window",
		})
		if err != nil {
			log.Fatal(err)
		}
		defer w.Release()

		var (
			buf   screen.Buffer
			bufSz image.Point
		)
		releaseBuf := func() {
			if buf != nil {
				buf.Release()
				buf = nil
			}
		}
		defer releaseBuf()

		for {
			switch e := w.NextEvent().(type) {
			case lifecycle.Event:
				if e.To == lifecycle.StageDead {
					return
				}

			case size.Event:
				need := e.Size()
				if need.X <= 0 || need.Y <= 0 {
					break
				}
				if buf == nil || need != bufSz {
					releaseBuf()
					var err error
					buf, err = s.NewBuffer(need)
					if err != nil {
						log.Fatal(err)
					}
					bufSz = need
					draw.Draw(buf.RGBA(), buf.Bounds(), &image.Uniform{color.RGBA{0x22, 0x44, 0x88, 0xff}}, image.Point{}, draw.Src)
					w.Send(paint.Event{})
				}

			case paint.Event:
				if buf == nil {
					continue
				}
				w.Upload(image.Point{}, buf, buf.Bounds())
				w.Publish()

			case error:
				log.Print(e)
			}
		}
	})
}

Run locally (from the directory that contains this main.go):

go run .

Handle Events in a Shiny Application

NextEvent blocks until the deque delivers something. Besides lifecycle, paint, and size, you will commonly see key.Event and mouse.Event.

Close the window with lifecycle.Event

When the user closes the window, you should see a lifecycle transition to lifecycle.StageDead. Return from driver.Main’s callback to exit cleanly (after releasing buffers and textures you allocated).

Handle keyboard and mouse input

• Keyboard — inspect e.Code (see key.Code) and e.Direction (key.DirPress, key.DirRelease, …).
• Mouse — e.X / e.Y, e.Button, and e.Direction describe clicks and movement in window coordinates.

This minimal program only logs input; it illustrates the type switch without drawing:

package main

import (
	"fmt"
	"log"

	"golang.org/x/exp/shiny/driver"
	"golang.org/x/exp/shiny/screen"
	"golang.org/x/mobile/event/key"
	"golang.org/x/mobile/event/lifecycle"
	"golang.org/x/mobile/event/mouse"
)

func main() {
	driver.Main(func(s screen.Screen) {
		w, err := s.NewWindow(&screen.NewWindowOptions{
			Title: "Shiny input demo",
		})
		if err != nil {
			log.Fatal(err)
		}
		defer w.Release()

		for {
			switch e := w.NextEvent().(type) {
			case lifecycle.Event:
				if e.To == lifecycle.StageDead {
					return
				}

			case key.Event:
				if e.Code == key.CodeEscape && e.Direction == key.DirPress {
					return
				}
				if e.Code == key.CodeSpacebar && e.Direction == key.DirPress {
					fmt.Println("space")
				}

			case mouse.Event:
				if e.Button == mouse.ButtonLeft && e.Direction == mouse.DirPress {
					fmt.Printf("click at (%.0f, %.0f)\n", e.X, e.Y)
				}

			case error:
				log.Print(e)
			}
		}
	})
}

Draw Graphics on a Shiny Window

Use Buffer, Upload, and Publish

1. Allocate a Buffer with s.NewBuffer(size image.Point).
2. Draw into buf.RGBA() with Set, image/draw, or your own raster code.
3. Call w.Upload(dp, buf, sr) to copy a rectangle of pixels into the window’s back buffer (dp aligns sr.Min in buffer space).
4. Call w.Publish() to swap buffers and show the result.

screen package documentation states that uploads to a window have no visible effect until Publish.

Redraw content on paint.Event

Treat paint.Event as “compose a frame now.” External paints arrive when the OS exposes or resizes the surface; internal paints are ones you enqueue with w.Send(paint.Event{}) after your own state changes.

Build a Small Interactive Example

Draw a box and move it with keyboard input

This program combines size.Event, paint.Event, and arrow keys. After each key press it enqueues a paint so the frame updates without waiting for the OS.

package main

import (
	"image"
	"image/color"
	"image/draw"
	"log"

	"golang.org/x/exp/shiny/driver"
	"golang.org/x/exp/shiny/screen"
	"golang.org/x/mobile/event/key"
	"golang.org/x/mobile/event/lifecycle"
	"golang.org/x/mobile/event/paint"
	"golang.org/x/mobile/event/size"
)

const box = 40

func main() {
	driver.Main(func(s screen.Screen) {
		w, err := s.NewWindow(&screen.NewWindowOptions{
			Title: "Move the box (arrow keys, Esc to quit)",
		})
		if err != nil {
			log.Fatal(err)
		}
		defer w.Release()

		var (
			buf     screen.Buffer
			bufSz   image.Point
			boxPos  = image.Pt(80, 60)
			pending bool
		)
		releaseBuf := func() {
			if buf != nil {
				buf.Release()
				buf = nil
			}
		}
		defer releaseBuf()

		requestPaint := func() {
			if !pending {
				pending = true
				w.Send(paint.Event{})
			}
		}

		for {
			switch e := w.NextEvent().(type) {
			case lifecycle.Event:
				if e.To == lifecycle.StageDead {
					return
				}

			case size.Event:
				need := e.Size()
				if need.X <= 0 || need.Y <= 0 {
					break
				}
				if buf == nil || need != bufSz {
					releaseBuf()
					var err error
					buf, err = s.NewBuffer(need)
					if err != nil {
						log.Fatal(err)
					}
					bufSz = need
				}
				requestPaint()

			case key.Event:
				if e.Direction != key.DirPress {
					break
				}
				switch e.Code {
				case key.CodeEscape:
					return
				case key.CodeUpArrow:
					boxPos.Y -= 10
				case key.CodeDownArrow:
					boxPos.Y += 10
				case key.CodeLeftArrow:
					boxPos.X -= 10
				case key.CodeRightArrow:
					boxPos.X += 10
				default:
					continue
				}
				requestPaint()

			case paint.Event:
				pending = false
				if buf == nil {
					continue
				}
				rgba := buf.RGBA()
				bounds := rgba.Bounds()
				max := bounds.Max
				if boxPos.X < bounds.Min.X {
					boxPos.X = bounds.Min.X
				}
				if boxPos.Y < bounds.Min.Y {
					boxPos.Y = bounds.Min.Y
				}
				if boxPos.X+box > max.X {
					boxPos.X = max.X - box
				}
				if boxPos.Y+box > max.Y {
					boxPos.Y = max.Y - box
				}

				draw.Draw(rgba, bounds, &image.Uniform{color.RGBA{0xf0, 0xf0, 0xf0, 0xff}}, image.Point{}, draw.Src)
				br := image.Rect(boxPos.X, boxPos.Y, boxPos.X+box, boxPos.Y+box)
				draw.Draw(rgba, br, &image.Uniform{color.RGBA{0xd4, 0x2c, 0x3c, 0xff}}, image.Point{}, draw.Src)

				w.Upload(image.Point{}, buf, buf.Bounds())
				w.Publish()

			case error:
				log.Print(e)
			}
		}
	})
}

Shiny Cheat Sheet

For image decoding and textures, see the basic and imageview upstream examples.

Common Errors and Troubleshooting

Window opens and closes immediately

Typical causes: returning from driver.Main before the loop runs, panicking during setup, or exiting on the first lifecycle event without checking To / direction. Ensure you only return on lifecycle.StageDead (or explicit quit) and that NewWindow errors are handled rather than ignored.

Drawing does not appear until paint.Event

Upload alone does not present a frame; call Publish after you finish drawing for this frame. If you mutate pixels in response to input, enqueue w.Send(paint.Event{}) so a paint happens—otherwise you might only see updates when the OS sends an external paint.

Buffer size does not match the window size

If Upload uses buf.Bounds() while the window has resized, you can see clipping, stretching, or stale borders. Recreate your buffer when size.Event reports a new WidthPx/HeightPx, then redraw and Send a paint.

Should You Use Golang Shiny Today?

When Shiny is useful

Shiny fits learning, prototypes, and custom renderers where you want thin abstraction over buffers and events, or you are following the official shiny/example programs. It can be a reasonable playground before committing to a larger GUI ecosystem.

When to consider Fyne, Gio, Ebiten, or Wails instead

For production desktop products, a maintained toolkit or a hosted UI usually beats an x/exp experiment on support and predictability.

References

• Package golang.org/x/exp/shiny
• Package golang.org/x/exp/shiny/driver
• Package golang.org/x/exp/shiny/screen
• Package golang.org/x/mobile/event
